NBR100

Full Gigabit Multi-WAN Port Internet Behavior Management Enterprise Router

1.6GHz dual core high performance processor

Full Gigabit interface adapt to bandwidth over 500M;

1-4 variable WAN ports, load balancing;

Thousands of Internet applications;

Stable capacity of 100 units;

AP management template automatically delivered;

Cloud platform management, convenient and efficient remote operation and maintenance

Product model	NBR100
Standard protocol	IEEE802.3,IEEE802.3u,IEEE802.3z ,IEEE802.3x,IEEE802.1x
Port	LAN port：4100/1000M AUTO MDI/MDIX RJ45 ports WAN port：1100/1000M AUTO MDI/MDIX RJ45 ports WAN/LAN port：3*100/1000M AUTO MDI/MDIX RJ45 ports
Forwarding rate	10/100/1000Mbps
CPU	880MHz*2
FLASH	16MB
Memory	128MB
LED display	PWR、SYS、Port status
Button	1*Reset
Size	200124.428mm
Power	12V/1A
Working environment	Operating temperature: 0°C ~ 40°C Storage temperature: -20°C ~ 70°C Operating humidity: 10% ~ 90%, non-condensing Storage humidity: 5% ~ 90%, non-condensing

Setup wizard	Quick guide Expert guide
System status	Overview State System log Host monitoring Real time monitoring Historical monitoring App statistics QQ online list Interface overview
Network settings	Extranet settings Intranet settings DHCP DNS Dynamic domain name Static routing Host name Interface settings Port mapping uPnP settings Switch
AC management	AC control AP settings control AP template settings AP radio settings AP advanced settings AP device management AP settings upgrade
Flow control multi-wire	Multi-line strategy Single line multi-dial Intelligent flow control Fixed flow control
Group management	IP group Time group Port group App group MAC group Domain name group
Behavior management	One-click control QQ whitelist Firewall rules URL redirection URL filtering DNS filtering WEB access record
Virtual private network	PPTP server PPTP client L2TP server L2TP client IPSEC
Advanced features	Anti-secondary routing Shared decipher PPPoE relay Port mirroring Wake on LAN
System management	System settings Toolbox Long ping Join the cloud Timed task Router password Firmware upgrade Feature library upgrade Reset Backup/restore
